产品选择器
22 个效果
Loading
|
Part No
|
Status
|
Vin_min (V)
|
Vin_max (V)
|
Output Current (A)Max
|
Vout_min (V)
|
Vout_max(V)
|
Ground Current (μA)
|
PSRR(db)
|
Dropout Voltage (mV)
|
Operating Temperature Range(°C)
|
Package
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| MP | 1.1 | 6.5 | 3 | 0.5 | 5.2 | 3000 | 42@10kHz | 180 @ 3A with Bias | -40 to +125 | QFN20 | |
| MP | 1.1 | 6.5 | 3 | 0.8 | 5.2 | 3000 | 42@10kHz | 180 @ 3A with Bias | -40 to +125 | QFN20 | |
| MP | 1.1 | 6.5 | 1.2 | 0.8 | 5.5 | 3000 | 40@500kHz | 70 @ 1.2A with Bias | -40 to +125 | DFN8 | |
| MP | 1.1 | 6.5 | 2 | 0.8 | 5.2 | 3000 | 39@500KHz | 125 @ 2A with Bias | -40 to +125 | QFN20 | |
| MP | 1.1 | 6.5 | 3 | 0.5 | 5.2 | 3000 | 39@500KHz | 180 @ 3A with Bias | -40 to +125 | QFN12 | |
| MP | 1.4 | 6.5 | 2 | 0.5 | 5.2 | 3000 | 39@500KHz | 300 @ 2A | -40 to +125 | SOP8 | |
| MP | 1.4 | 6.5 | 2 | 0.5 | 5.2 | 3000 | 39@500KHz | 300 @ 2A | -40 to +125 | TO263 | |
| MP | 1.4 | 6.5 | 2 | 0.5 | 5.2 | 3000 | 39@500KHz | 180 @ 2A | -40 to +125 | QFN16 | |
| MP | 1.4 | 6.5 | 1.2 | 0.5 | 5.2 | 3000 | 39@500KHz | 200 @ 2A | -40 to +125 | DFN8 | |
| MP | 1.4 | 6.5 | 3 | 0.5 | 5.2 | 3000 | - | 300 @ 2A | -40 to +125 | TO263 | |
| MP | 1.9 | 5.5 | 0.3 | 0.8 | 3.6 | 0.8 | 50@1KHz | 180 @ 0.2A | -40 to +125 | SOT235/SOT233/DFN 1x1 | |
| MP | 2.5 | 5.5 | 0.3 | 1.2 | 5 | 0.3 | 60@1KHz | 270 @ 0.2A | -40 to +85 | SOT235/SOT233/DFN 1x1 | |
| MP | 1.5 | 7 | 0.5 | 0.8 | 5 | 40 | 87@1KHz | 520 @ 0.2A | -40 to +125 | SOT235/DFN 1x1 | |
| MP | 1.8 | 7 | 0.5 | 1.2 | 5 | 40 | 80@1KHz | 270 @ 0.2A | -40 to +85 | SOT233/DFN 1x1 | |
| MP | 2.3 | 10 | 0.4 | 1.5 | 5 | 2.1 | 76@1KHz | 300 @ 0.2A | -40 to +85 | SOT235/SOT233/DFN 1x1/SOT893 | |
| MP | 2.5 | 45 | 0.35 | 1.8 | 5 | 2.5 | 60@1KHz | 690 @ 0.2A | -40 to +125 | SOT235/SOT233/DFN 1x1/SOT893 | |
| MP | 2.5 | 36 | 0.25 | 1.8 | 5 | 2.5 | 60@1KHz | 690 @ 0.2A | -40 to +125 | SOT235/SOT233/DFN 1x1/SOT893 | |
| MP | 3 | 30 | 0.2 | 3 | 5 | 1.5 | 40@1KHz | 1000/1200 @ 0.2A | -40 to +125 | SOT235/SOT233/SOT893 | |
| MP | 3 | 30 | 0.2 | 3 | 5 | 1.5 | 40@1KHz | 1000 @ 0.2A | -40 to +125 | SOT235/SOT233/SOT893 | |
| MP | 3 | 40 | 0.2 | 3 | 5 | 2.5 | 70@1KHz | 1600 @ 0.2A | -40 to +125 | SOT235/SOT233/SOT893 | |
| MP | 18 | 0.8 | 1.8 | 5 | 3500 | 70@120Hz | 1200 @ 0.8A | -40 to +125 | SOT223/SOT89 | ||
| MP | 30 | 0.15 | 5 | 5.1 | 1300 | 62@120Hz | 1800 @ 0.15A | -40 to +125 | SOT89/TO92 |
